ENTTEC – DMX

Specification
Connectors
1* DMX Output
(Female XLR5)
1* USB 2.0 Type-B
IP rating IP20
LED indicators No
Supported protocols USITT DMX512-A
Standalone playback No
MIDI No
Maximum output
channels 1 universe (512ch)1
Max. output refresh rate 40FPS2
Configuration software No
Firmware updates No
Input voltage 5V DC (via USB)
Input current 300mA
Power draw 1.5W
Environmental Operating
temperature
0°-50°C
32°-122°F
Environmental Operating
humidity
5- 95%
(non-condensing)
Body material Folded Aluminium
Mounting options N/A
Unit dimensions 77x40x40 mm
Unit weight 61 g / 0.13lbs
Shipping dimensions 125x75x70 mm
Shipping weight 0.16kg / 0.35lbs
Warranty 3-year return to base
manufacturer warranty
